Dimensions |
Floor plates, multipart |
Base frames H = 100 mm |
Adapter sets for assembly kits acc. to DIN 43870 (8GK system) (incl. longitudinal stays 1 right and 1 left) |
||
|---|---|---|---|---|---|
|
H |
D |
B |
Order No. |
Order No. |
Order No. |
|
mm |
mm |
mm |
|||
|
2000 |
400 |
400 |
8GG3 361-0 |
8GG3 401-0 |
8GK9 400-0KK15 |
|
600 |
8GG3 362-0 |
8GG3 402-0 |
8GK9 400-0KK25 |
||
|
850 |
8GG3 364-0 |
8GG3 404-0 |
8GK9 400-0KK35 |
||
|
1100 |
8GG3 366-0 |
8GG3 406-0 |
8GK9 400-0KK45 |
||
|
600 |
400 |
8GG3 361-1 |
8GG3 401-1 |
8GK9 400-0KK17 |
|
|
600 |
8GG3 362-1 |
8GG3 402-1 |
8GK9 400-0KK27 |
||
|
850 |
8GG3 364-1 |
8GG3 404-1 |
8GK9 400-0KK37 |
||
|
1100 |
8GG3 366-1 |
8GG3 406-1 |
8GK9 400-0KK47 |
||
 |
 |
 |
|||
|
Dimensions |
Front doors made of sheet steel |
Front doors made of glass |
Side panels (1 set = 2 side panels), closed: IP55 |
||
|---|---|---|---|---|---|
|
H |
D |
B |
Order No. |
Order No. |
Order No. |
|
mm |
mm |
mm |
|||
|
2000 |
400 |
400 |
8GG3 004-1 |
8GG3 044-2 |
8GG3 204-0 |
|
600 |
8GG3 004-2 |
8GG3 044-3 |
8GG3 204-0 |
||
|
850 |
8GG3 004-4 |
8GG3 044-4 |
8GG3 204-0 |
||
|
1100 |
8GG3 004-6 |
8GG3 044-5 |
8GG3 204-0 |
||
|
600 |
400 |
8GG3 004-1 |
8GG3 044-2 |
8GG3 204-1 |
|
|
600 |
8GG3 004-2 |
8GG3 044-3 |
8GG3 204-1 |
||
|
850 |
8GG3 004-4 |
8GG3 044-4 |
8GG3 204-1 |
||
|
1100 |
8GG3 004-6 |
8GG3 044-5 |
8GG3 204-1 |
||
 |
 |
 |
|||
