A5E003424739

Description

Article No.

Infrared optical head (Bluetooth type) for data acquisition & programming of FUE950

A5E02611768

Bracket for SITRANS FUE950 wall mounting (20 pcs.)

A5E02611769

Cable for data acquisition via RS 232 PC/D-sub 9F/3 wire

A5E02611774

Basic version of programming software tool for FUE950

free download from internet

Expert version of programming software tool for FUE950

A5E03478951

Test Lab. version of re-programming software tool for FUE950
(Note: Before using this Test-Lab version an online training must be completed)

A5E03461778

Description

Article No.

Add-on modules for FUE950 (only for 7ME348 versions)

Pulse input module (2 inputs)

A5E03461432

Pulse output module (2 outputs)

A5E03461436

Combined pulse in-/output module (2 inputs and 1 output)

A5E03461437

RS232 module (M-Bus protocol)

A5E03461459

RS485 module (M-Bus protocol)

A5E03461512

M-Bus output module

A5E03461516

Combined current output module, 2 x passive 4 ... 20 mA

A5E03461583

Connection set for option modules (types: Pulse, RS 232/RS 485, M-Bus, mA) (special connection cable with 2 plugs)

A5E03461585

Power supply for FUE950 (only for 7ME348 versions)

3.6 V D-cell battery for SITRANS FUE950

A5E03461708

230 V AC supply module (incl. internal fuse T50 mA L 250 V and back-up battery) for SITRANS FUE950

A5E03461717

24 V AC supply module for SITRANS FUE950, incl. back-up battery

A5E03461719

Pocket for temperature sensors Pt500 (for related 4-wire Pt500 type only, 1 pc.)

Stainless steel pocket (1 pc.), 135 mm length for 6 mm sensor diameter, max. PN 40 and max. 5 m/s (recommended for 140 mm sensor length).

A5E03462868

Stainless steel pocket (1 pc.), 225 mm length for 6 mm sensor diameter, max. PN 40 and max. 5 m/s (recommended for 230 mm sensor length).

A5E03462870

Pt500 4-wire temperature sensor pair (as spare part), with MID MI004 and PTB K7.2 approvals and verification (for related 4-wire sensor pocket types only)

Pt500 sensor pair (6/140 mm), 4-wire with 5 m connection cable, 6 mm sensor diameter and 140 mm sensor length. MID approved DE-06-MI004-PTB011, PTB approved 22.77/09.01 (mentioned approvals are only valid if temp. sensors are used with the applicable temperature sensor pockets).

A5E03462872

PT500 sensor pair (6/230 mm), 4-wire with 5 m connection cable, 6 mm sensor diameter and 230 mm sensor length. MID approved DE-06-MI004-PTB011, PTB approved 22.77/09.01 (mentioned approvals are only valid if temp. sensors are used with the applicable temperature sensor pockets).

A5E03462878

FUE950 enclosure (only for 7ME348 versions)

Bottom part of FUE950 enclosure (1 pc.)

A5E03461508

Snap fit for FUE950 enclosure (1 pc.)

A5E03461731

Pocket for Pt500 temperature sensors (for corresponding 2-wire Pt500 types only; 1 pc.)

Brass pocket 6 mm, G?B x 40 mm (PN 16), 1 pc.

A5E02611778

Brass pocket 6 mm, G?B x 85 mm (PN 16), 1 pc.

A5E02611779

Brass pocket 6 mm, G?B x 120 mm (PN 16), 1 pc.

A5E02611780

Stainless steel 6 mm, G?B x 85 mm (PN 25), 1 pc.

A5E02611781

Stainless steel 6 mm, G?B x 120 mm (PN 25), 1 pc.

A5E02611783

Stainless steel 6 mm, G?B x 155 mm (PN 25), 1 pc.

A5E02611792

Stainless steel 6 mm, G?B x 210 mm (PN 25), 1 pc.

A5E02611793

Pt500 temperature sensor pair, 2-wire cable, 6 mm sensor diameter, with MID/EN-approval (for corresponding 2-wire sensor pocket types only)

Cable length:

2 m

A5E02611794

3 m

A5E02611795

5 m

A5E02611796

10 m

A5E02611798
