Identification letter

13 functions

1 CO contact (1 CO), 1 NO contact (1 NO) semiconductor or 2 CO contacts switching in parallel (2 CO)

27 functions

13 functions (A - M) 2 CO contacts switching in parallel (2 CO) + 13 functions (A - M) 1 CO delayed contact + 1 CO instantaneous contact (1 CO + 1 CO) and wye-delta function

A

ON-delay

ON-delay and instantaneous contact

B

OFF-delay with control signal

OFF-delay with control signal and instantaneous contact

C

ON-delay / OFF-delay with control signal

ON-delay / OFF-delay with control signal and instantaneous contact

D

Flashing, symmetrical, starting with interval

Flashing, symmetrical, starting with interval and instantaneous contact

E

Passing make contact, interval relay

Passing make contact, interval relay and instantaneous contact

F

Retrotriggerable interval relay with deactivated control signal (passing break contact with control signal)

Retrotriggerable interval relay with deactivated control signal (passing break contact with control signal) and instantaneous contact

G

Passing make contact with control signal, not retrotriggerable, (pulse-forming with control signal)

Passing make contact with control signal, not retrotriggerable, (pulse-forming with control signal) and instantaneous contact

H

Additive ON-delay, instantaneous OFF with control signal

Additive ON-delay, instantaneous OFF with control signal and instantaneous contact

I

Additive ON-delay with control signal

Additive ON-delay with control signal and instantaneous contact

J

Flashing, symmetrical, starting with pulse

Flashing, symmetrical, starting with pulse and instantaneous contact

K

Pulse delay (pulse permanently set (to 1 s) and pulse delay adjustable)

Pulse delay (pulse permanently set (to 1 s) and pulse delay adjustable) and instantaneous contact

L

Pulse delay with control signal (pulse permanently set (to 1 s) and pulse delay adjustable)

Pulse delay with control signal (pulse permanently set (to 1 s) and pulse delay adjustable) and instantaneous contact

M

Retrotriggerable interval relay with activated control signal (watchdog)

Retrotriggerable interval relay with activated control signal and instantaneous contact (watchdog)

--

Wye-delta function

Article number 3RP15

Article number 3RP25

3RP1505

3RP1505-1AA40

3RP2505-1AW30

3RP1505-1AP30

3RP2505-1AB30¹⁾, 3RP2505-1AW30

3RP1505-2AP30

3RP2505-2AB30¹⁾, 3RP2505-2AW30

3RP1505-1AQ30

3RP2505-1AB30¹⁾, 3RP2505-1AW30

3RP1505-2AQ30

3RP2505-2AB30¹⁾, 3RP2505-2AW30

3RP1505-1AW30

3RP2505-1AW30

3RP1505-2AW30

3RP2505-2AW30

3RP1505-1BP30

3RP2505-1BB30¹⁾, 3RP2505-1BW30

3RP1505-2BP30

3RP2505-2BB30¹⁾, 3RP2505-2BW30

3RP1505-1BQ30

3RP2505-1BB30¹⁾, 3RP2505-1BW30

3RP1505-2BQ30

3RP2505-2BB30¹⁾, 3RP2505-2BW30

3RP1505-1BW30

3RP2505-1BW30

3RP1505-2BW30

3RP2505-2BW30

3RP2505-1BT20

3RP2505-1BT20

3RP1505-1RW30

On request

3RP1505-2RW30

On request

3RP1511

3RP1511-1AP30

3RP2511-1AW30

3RP1511-2AP30

3RP2511-2AW30

3RP1511-1AQ30

3RP2511-1AW30

3RP1511-2AQ30

3RP2511-2AW30

3RP1512

3RP1512-1AP30

3RP2512-1AW30

3RP1512-2AP30

3RP2512-2AW30

3RP1512-1AQ30

3RP2512-1AW30

3RP1512-2AQ30

3RP2512-2AW30

3RP1513

3RP1513-1AP30

3RP2513-1AW30

3RP1513-2AP30

3RP2513-2AW30

3RP1513-1AQ30

3RP2513-1AW30

3RP1513-2AQ30

3RP2513-2AW30

3RP1525

3RP1525-1AP30

3RP2525-1AW30

3RP1525-2AP30

3RP2525-2AW30

3RP1525-1AQ30

3RP2525-1AW30

3RP1525-2AQ30

3RP2525-2AW30

3RP1525-1BP30

3RP2525-1BB30¹⁾, 3RP2525-1BW30

3RP1525-2BP30

3RP2525-2BB30¹⁾, 3RP2525-2BW30

3RP1525-1BQ30

3RP2525-1BB30¹⁾, 3RP2525-1BW30

3RP1525-2BQ30

3RP2525-2BB30¹⁾, 3RP2525-2BW30

3RP1525-1BR30

3RP2525-1BW30

3RP1525-2BR30

3RP2525-2BW30

3RP1525-1BW30

3RP2525-1BW30

3RP1525-2BW30

3RP2525-2BW30

3RP1527

3RP1527-1EC30

3RP2527-1EW30

3RP1527-2EC30

3RP2527-2EW30

3RP1527-1EM30

3RP2527-1EW30

3RP1527-2EM30

3RP2527-2EW30

3RP1531

3RP1531-1AP30

3RP2535-1AW30

3RP1531-2AP30

3RP2535-2AW30

3RP1531-1AQ30

3RP2535-1AW30

3RP1531-2AQ30

3RP2535-2AW30

3RP1532

3RP1532-1AP30

3RP2535-1AW30

3RP1532-2AP30

3RP2535-2AW30

3RP1532-1AQ30

3RP2535-1AW30

3RP1532-2AQ30

3RP2535-2AW30

3RP1533

3RP1533-1AP30

3RP2535-1AW30

3RP1533-2AP30

3RP2535-2AW30

3RP1533-1AQ30

3RP2535-1AW30

3RP1533-2AQ30

3RP2535-2AW30

3RP1540

3RP1540-1AB31

3RP2540-1AB30

3RP1540-2AB31

3RP2540-2AB30

3RP1540-1AJ31

3RP2540-1AW30

3RP1540-2AJ31

3RP2540-2AW30

3RP1540-1AN31

3RP2540-1AW30

3RP1540-2AN31

3RP2540-2AW30

3RP1540-1AW31

3RP2540-1AW30

3RP1540-2AW31

3RP2540-2AW30

3RP1540-1BB31

3RP2540-1BB30

3RP1540-2BB31

3RP2540-2BB30

3RP1540-1BJ31

3RP2540-1BW30

3RP1540-2BJ31

3RP2540-2BW30

3RP1540-1BN31

3RP2540-1BW30

3RP1540-2BN31

3RP2540-2BW30

3RP1540-1BW31

3RP2540-1BW30

3RP1540-2BW31

3RP2540-2BW30

3RP1555

3RP1555-1AR30

3RP2555-1AW30

3RP1555-2AR30

3RP2555-2AW30

3RP1555-1AP30

3RP2555-1AW30

3RP1555-2AP30

3RP2555-2AW30

3RP1555-1AQ30

3RP2555-1AW30

3RP1555-2AQ30

3RP2555-2AW30

3RP1560

3RP1560-1SP30

3RP2560-1SW30

3RP1560-2SP30

3RP2560-2SW30

3RP1560-1SQ30

3RP2560-1SW30

3RP1560-2SQ30

3RP2560-2SW30

3RP1574

3RP1574-1NP30

3RP2574-1NW30

3RP1574-2NP30

3RP2574-2NW30

3RP1574-1NQ30

3RP2574-1NW30

3RP1574-2NQ30

3RP2574-2NW30

3RP1574-1NM20

3RP2574-1NM20

3RP1574-2NM20

3RP2574-2NM20

3RP1576

3RP1576-1NP30

3RP2576-1NW30

3RP1576-2NP30

3RP2576-2NW30

3RP1576-1NQ30

3RP2576-1NW30

3RP1576-2NQ30

3RP2576-2NW30

3RP1576-1NM20

3RP2576-1NM20

3RP1576-2NM20

3RP2576-2NM20
