Dimensions

• Width / Length / Cover width in mm

6,2 / 57,8 / --

8,2 / 57,8 / --

• Height (NS 35/7,5 / NS 35/15) in mm

73 / 80,5

Technical specifications according to IEC/ DIN VDE

• Max. load current in A¹⁾ / cross-section in mm?

6,3 / 6

10 / 10

• Rated impulse (withstand) voltage in kV / pollution degree

6 kV/3

4 kV/3

8 kV/3

6 kV/3

• Rated insulation voltage (working voltage) U_i in V according to IEC 60497-7-1

500

630

• Overvoltage category / insulating group

III / I

Connection capacity

• Flexible with end sleeve, with plastic sleeve in mm?

0,25 ... 4

0,25 ... 6

• Flexible with end sleeve, without plastic sleeve in mm?

0,25 ... 4

0,25 ... 6

• Flexible with two-wire connection end sleeve, with plastic sleeve in mm?

0,5 ... 2,5

0,5 ... 4

• rigid in mm?

0,14 ... 6

0,2 ... 10

Stripped length in mm

9

10

Molded plastic type

PA

• Flammability class according to UL 94

V0

Approval data (UL/CUL and CSA)

• Rated voltage / rated current / conductor sizes

• UL/CUL: in V/A / AWG

600 / 6,3 / 26-10

600 / 16 / 24-8

• CSA: in V/A / AWG

600 / 6,3 / 26-10

-- / -- / --
