6SL3700-0MX14-0AA3
|
6SL3700-0MX16-3AA3
|
6SL3700-0MX21-0AA3
|
6SL3700-0MX21-4AA3
|
|
System-side power supply
380 … 690 V 3 AC
|
A
|
125
|
160
|
200
|
250
|
|
Line supply connection
|
|
|
|
|
|
- Conductor cross-section, max. (IEC)
|
mm2
|
150
|
150
|
150
|
150
|
|
Current carrying capacity, max.
|
|
|
|
|
|
- Load connection
380 V … 690 V AC
|
|
|
|
|
|
- to auxiliary power supply
|
A
|
63
|
80
|
100
|
100
|
- to customer terminal -X45
|
A
|
50
|
63
|
80
|
80
|
- Load connection
230 V 2 AC
|
|
|
|
|
|
- to auxiliary power supply
|
A
|
6
|
10
|
10
|
20
|
- to customer terminal -X45
|
A
|
8
|
10
|
10
|
20
|
|
|
|
|
|
|
|
- to auxiliary power supply
|
A
|
20
|
40
|
80
|
80
|
|
Cable cross-section, max.
|
|
|
|
|
|
|
|
mm2
|
16
|
16
|
16
|
16
|
|
|
mm2
|
2.5
|
2.5
|
2.5
|
2.5
|
|
Cooling air requirement
|
m3/s
|
Natural convection
|
Natural convection
|
Natural convection
|
Natural convection
|
|
PE/GND connection
|
|
PE bar
|
PE bar
|
PE bar
|
PE bar
|
|
|
mm2
|
600
|
600
|
600
|
600
|
- Conductor cross-section, max. (IEC)
|
mm2
|
240
|
240
|
240
|
240
|
|
Degree of protection
|
|
IP20
|
IP20
|
IP20
|
IP20
|
|
Dimensions
|
|
|
|
|
|
|
|
mm
|
600
|
600
|
600
|
600
|
|
|
mm
|
2200
|
2200
|
2200
|
2200
|
|
|
mm
|
600
|
600
|
600
|
600
|
|
Weight, approx.
|
kg
|
170
|
180
|
210
|
240
|
